(Revised 2015-09-28) Page 12 of 157
FRONT PANEL
From Top to Left:
RJ45 Ports Auto Sensing 10/100 Base-TX Connections
Fiber Ports 100 Base-FX Connections (only on 708FX2 model)
LED lights when Power is supplied to the unit
NOTE: The RJ45 data port has two LEDs located on each connector. The left LED indicates LINK status,
and the right LED indicates ACTIVITY.
LEDs: The table below describes the operating modes:
Power is ON and a fault condition exists
10/100Mb Link between ports
Data is active between ports
Data is inactive between ports
