Nabco 710 - Single Door Conversion

Model 710 Swing Door System
NABCO
ENTRANCES INC 877-622-2694 www.nabcoentrances.com - 10 -
WIRE Hrness Clip P/N 24-1447
WIRE SADDLE P/N 14-9960
2. Push the Clip
into the Clip. 1. Insert wires
SCREWS & SPACERS P/N 24-4941-16 & 14-8743
MAGNUM IV BOARD P/N 24-8900-04
MAIN HARNESS P/N 22-10065
SINGLE DOOR CONVERSION of GT710
into the Extrusion.
DN0039
Figure 5 – Single Door Conversion of GT710
