GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16

1. Loosen (2) Eccentric Retainer Rollers located at the edge of Carrier.
2. Turn the Axle clockwise unl there is a 1/64 inch to 1/32 inch gap between the Roller Wheel and the Boom Track.
a. Gap should be about the same thickness of a credit card.
DN 0912
Eccentric Retainer
Roller Wheel
Bo om of Track
1/64 inch to
1/32 inch
clearance
Figure 32 Eccentric Retainer Roller Wheel and Bottom of Track Clearance

1. Manually close the Slide Door.
2. Ensure there is approximately 1/8 inch gap between the male Interlock and the Female Interlock.
a. The Slide door will not operate properly if the gap is less than 1/8 inch.
3. Loosen mounng screws to adjust one or both Interlocks.
4. Reghten Mounng screws once gap is appropriate width.
Figure 33 Adjust Interlock
DN 0928
Female
Interlock
Male
Interlock
1/8”Gap
Strike S le
(Interior Face of Swing Sidelite)
Female Interlock
Pivot S le
(Exterior Face of Slide Door)
Male Interlock
Strike S le
Pivot S le

Note: Glass must be installed rst before adjusng the Preload on Slide Door.
5. Support the weight of Slide Door. Then Breakout approximately 5 degrees.
a. Just enough to expose the Preload Adjustment Screw located on back edge of door.
b. Fixed sidelite must not come into contact with other doors.
Figure 34 Check Door Sag
DN 0726
Pivot Block
Pivot bar
Door Sag
Preload Adjustment Screw
Preload Adjust
Carrier
