Nabco Opus Control Wiring And Programming Installation Manual

3 of 32
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 10-20-17 P/N C-00139
CHAPTER 2: SCOPE
SECTION 2.1: To the Installer
The purpose of this manual is to familiarize the installer with the proper installaon and operaon of this system. It is essenal
that this equipment be properly installed and operaonal before the door is used by the public. It is the installer’s responsibility
to inspect the operaon of the entrance system to be sure it complies with any applicable standards. In the United States, ANSI
Standard 156.10 (Used to cover Full Energy doors) and ANSI Standard 156.19 (Used to cover Low Energy doors) apply. Other local
standards or codes may apply. Use them in addion to the ANSI standards.
The owner should determine the door is operang properly and should immediately call for service if there is any malfuncon. All
installaon changes and adjustments must be made by qualied, NABCO trained technicians.
If aer troubleshoong a problem, a sasfactory soluon cannot be achieved, please call Nabco Entrances at 1-877-622-2694
between 8 am – 4:30 pm Central me for addional assistance.
SECTION 2.2: Objecve
The Opus Control is designed to be installed within the Header of:
X New Swing and Folding Doors.
X Existing swing and folding doors using Analog, Magnum, or U01-U19 controls (works with encoders or
microswitches).
X 
1-888-679-3319.
This manual oers step by step instrucons. Do Not take shortcuts.
CHAPTER 3: FEATURES
Specification Description
Power Close Built-in
Back Check Angle Adjustment
►  ► 
Latch Check Angle Adjustment
►  ► 
Built In Sequencer Can acvate:
► Electric Locks
► Electric Strikes
► 
CHAPTER 4: SPECIFICATIONS
SECTION 4.1 General Specicaons
Specification Description
Temperature Range -13 degrees to 140 degrees Fahrenheit
Motor Type DC Brush Motor with Encoder, 115V
Number of Signal Inputs
►  ► 2 x Door Mode
►  ► 1 x Sequential
►  ► 
Number of Outputs
► 
► 
SECTION 4.2 Electrical Specicaons
Note: All Wiring Diagrams included within this manual, reect typical primary and secondary circuits that might be commonly
used. On site wiring may be dierent from that shown.
Note: NABCO factory ulizes Underwriters Laboratories (UL) recognized component wire, terminals and connector housings to
manufacture all Automac Door systems.
