4 of 32
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 10-20-17
Table 1 Wiring
Item Description
Power Input 100VAC - 130 VAC, AC 50-60 Hz; 3A (NABCO recommends min. 5A service)
Power for accessories 12VDC; 750mA
Output Rang Transistor Output; 100mA @ 12VDC
F1 Fuse 120VAC Power Circuit of Control
Table 2
Sensor Part Number Current Consumption
Acuvision V-00202 80mA
(ea.unit) at 12VDC
Optex Reacon V-00173 125mA
Acusensor M A-01306 150mA
Optex i-one V-00055 130mA
Radio Control Receiver 24-11467 50mA
CX33 Logic Relay V-00734 320mA
SECTION 4.3 Output Power Guidelines
TOTAL current draw from the Opus Control must not exceed 0.7A when providing power to:
X Sensors X Modules X Accessories X
If TOTAL current draw exceeds 0.7A the installer must ulize an auxiliary power supply such as the NABCO Transformer 24 VAC,
P/N A-01185.
The Opus Control must Not be used to output power to:
X Magnec Locks X Electric Strikes
To determine if an auxiliary power supply must be used, add the total current draw of all devices. Please refer to the formula below:
2 x Acusensor M @ 150 mA = 300 mA
50 mA
350 mA
350mA does not exceed total current draw.
CHAPTER 5: 120 VAC GENERAL WIRING
Shut the installation site branch Circuit Breaker OFF. Failure to do so may result in serious
personal or fatal injury. When uncertain whether power supply is disconnected, always verify
using a voltmeter.
All high voltage electrical connections must be made by licensed electricians according to
National and Local electrical codes/regulations.
Permanent wiring shall be employed as required by local codes.
Electrical circuit to Nabco operator must not be not shared with other equipment such as
lighting, cash registers, or any device that might cause electrical interference on the circuit.
