Value
Unique in its blend of performance and flexibility, the C 245BEE is also a tremendous bargain. This is in keeping with NAD’s ‘giant slaying’ reputation where we are
often compared to products costing two or three times more, yet still come out on top. Honest musicality never goes out of style and the C 245BEE will provide you
many years of enjoyment.
> D E T A I L S C O N T I N U E D
Line IN (Channel A or B), Speaker OUT
Continuous output power into 8Ω and 4Ω (both channels driven) >35W (ref. rated THD, 20Hz – 20kHz)
Continuous output power into 8Ω (Mono, Bridge mode) >70W (ref. 20Hz - 20kHz, <0.02% THD)
Rated THD (250mW to rated power, CCIF IMD, DIM 100) <0.03% (ref. 20Hz - 20kHz)
IHF dynamic power 8Ω 55W
4Ω 85W
2Ω 95W
IHF dynamic power (Bridge mode) 8Ω 160W
4Ω 180W
Peak output current >20A (ref. 1Ω, 1ms)
Signal/Noise ratio >95dB (A-weighted, ref. 1W)
>110dB (A-weighted, ref. 35W)
Damping factor >180 (ref. 8Ω, 50Hz and 1kHz)
Frequency response ±0.3dB (ref. 20Hz - 20kHz)
3Hz - 100kHz (ref. -3dB)
Input impedance (R and C) 20kΩ + 470pF
Input sensitivity 270mV (ref. rated power)
Voltage gain 35dB
Minimum input level for AUTO TRIGGER 50mV at 1kHz
Time to power OFF at no signal in AUTO mode <10 minutes
POWER CONSUMPTION
Normal operation 270W (ref. 230V AC 50Hz; 120V AC 60Hz)
Standby power <1W
Idle power <55W
DIMENSIONS AND WEIGHT
Dimensions (W x H x D) 435 x 80 x 285mm (Net)
435 x 95 x 315mm (Gross)
Net Weight 7.3 kg
Shipping weight 8.8 kg
> S P E C I F I C A T I O N S
* Gross dimensions include feet, extended buttons and rear panel terminals.
Note: Installers should allow a minimum clearance of 55 mm for
wire/cable management.
