1 STANDBY BUTTON: Press this button to switch ON the C 245BEE.
The Standby LED indicator will turn from amber to blue. Pressing the
STANDBY button again turns the unit back to standby mode.
IMPORTANT NOTICE
The rear panel POWER switch must be in the ON position for the
STANDBY button to activate.
2 STANDBY LED: This indicator will light up amber when the C 245BEE
is in standby state. When the C 245BEE is at ON state, this indicator will
illuminate blue.
In cases of serious abuse of the C 245BEE, such as excessively low
loudspeaker impedance and short circuit, the C 245BEE will engage its
Protection circuitry, indicated by the Standby LED turning from blue to
red and the sound being muted.
In such a case, turn the C 245BEE OFF by the rear panel POWER switch,
wait for it to cool down and/or check the speaker connections, making
sure the overall loudspeaker impedance doesn’t go below 4 ohms or
8 ohms in Bridge mode. Once the cause for the protection circuitry to
engage has been removed, switch ON the rear POWER switch and the
Standby button to resume normal operation.
3 CHANNEL A: Press to select the input source connected at the rear
panel CHANNEL A input sockets.
4 CHANNEL B: Press to select the input source connected at the rear
panel CHANNEL B input sockets. Both CHANNEL A and CHANNEL B can
be activated at the same time if an input source is connected to their
respective rear panel channel input sockets.
IDENTIFICATION OF CONTROLS
FRONT PANEL
1 2 3 4
