NAD C 268 User Manual

QUICK START
Refer to the supplied C 268 Quick Setup Guide for basic instructions
in setting up your new NAD C 268. The following guidelines must be
observed when setting up your C 268.
1 Before setting up or making connections, ensure that the C 268 and other
devices to be connected to C 268 are unplugged or powered down.
2 Connect your speakers to the LEFT and RIGHT speaker terminals.
Connect the speaker cables to the corresponding speaker terminal
connections (R +/-, L +/-) as reected in the C 268 rear panel. Bare wire
or loose strands from the speaker cables must not touch the rear panel
or other speaker terminals.
3 Connect the line output terminal of your external sources to the
BALANCED and/or SINGLE-ENDED ANALOG AUDIO INPUT ports using
applicable connectors.
IMPORTANT NOTES
• The blue terminals must never be connected to ground (earth).
• Never connect the blue terminals together or to any common ground
device.
• Do not connect the output of this amplier to any headphone adapter,
speaker switch or any device that uses common ground for left and
right channels.
4 Connect corresponding end of the mains power cord to the AC mains
input of C 268 and the plug connected to a mains power source.
WARNING
For optimal performance, the C 268 requires a grounded AC receptacle
or a separate earth ground. Ensure the proper grounding of your system.
5 Maintain default settings of the following control switches’
• LEFT and RIGHT SELECT towards BALANCED or SINGLE-ENDED
(both switches must be of the same setting)
• INPUT SELECT to FIX
• AUTO SENSE LEVEL to MID
6 Set the POWER switch at the rear panel to “ON” setting. The Standby
LED indicator will illuminate amber. Press front panel STANDBY button
to turn ON the C 268. The Standby LED indicator will turn from amber
to blue. Your C 268 is now powered up!
SAVE THE PACKAGING
Please save the box and all of the packaging in which your C 268 arrived.
Should you move or otherwise need to transport your C 268, this is by far
the safest container in which to do so. We’ve seen too many otherwise
perfect components damaged in transit for lack of a proper shipping
carton, so please: Save that box!
NOTES ON INSTALLATION
• Place your NAD C 268 on a rm, level surface.
• Avoid placing the unit in direct sunlight or near sources of heat and
damp.
• Do not place the unit on a soft surface like a carpet.
• Do not place the C 268 in an enclosed position such as a bookcase
or cabinet that may impede the air-ow through the ventilation slots.
Allow adequate ventilation.
• Make sure the unit is switched o before making any connections.
• The RCA sockets on your C 268 are color coded for convenience. Red
and white are Right and Left audio respectively. Use high quality leads
and sockets for optimum performance and reliability.
• Ensure that leads and sockets are not damaged in any way and all
sockets are rmly pushed home.
• Should water get into your C 268, shut o the power to the unit and
remove the plug from the AC socket. Have the unit inspected by a
qualied service technician before attempting to use it again.
• Use a dry soft cloth to clean the unit. If necessary, lightly dampen the
cloth with soapy water. Do not use solutions containing benzol or other
volatile agents.
DO NOT REMOVE THE COVER; THERE ARE NO USERSERVICEABLE
PARTS INSIDE.
INTRODUCTION
GETTING STARTED
5
ENGLISHFRANÇAISESPAÑOLITALIANODEUTSCHNEDERLANDSSVENSKAРУССКИЙ

NAD C 268 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	20 - 20000 Hz
Input sensitivity	750 mV
Audio output channels	- channels
Peak power per channel	300 W
Signal-to-Noise Ratio (SNR)	0.3 dB
Total Harmonic Distortion (THD)	0.03 %
Dynamic power per channel (2 Ohm)	250 W
Dynamic power per channel (4 Ohm)	200 W
Dynamic power per channel (8 Ohm)	120 W
Power consumption (standby)	0.5 W
Package weight	8700 g
Product color	Black
Connectivity technology	Wired
LED indicators	Yes

Weight and Dimensions

Depth	390 mm
Width	435 mm
Height	100 mm
Weight	7300 g
