NAD C 356BEE - Electrical Parts List - Main Board; Main Board Integrated Circuits (ICs); Main Board Diodes; Main Board Transistors

CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC401 03-00317-00 LM317M
IC402 03-00337-00 LM337M
IC11, IC21, IC301 03-00431-03 AZ431BZ-B
IC41,IC42,IC43 03-00082-00 TL082CP/CN/D
IC44 02-01237-10
+DQVRQJ3URWHFWLRQ0RGXOH
DIODES
D320 33-05819-01 1N5819HW-7-F, 40V, 1A
D412, D413, D430 33-44148-17 1N4148W-NR,SOD123
D431, D432 33-12400-11 24V, 1/2W , LL34
D17, D27, D37, D38, D39,
D101, D102, D103, D201,
D202, D203, D310, D311,
D312, D313, D316, D317,
D417, D418, D419, D420,
D429
33-44148-00 1N4148
D428 33-44148-00 1N4148
D11, D12, D21, D22 33-14709-00 4.7V, 0.5W
D410, D411 33-12000-10 20V, 1W
D110, D111 33-13309-07 3.3V, 1W
TRANSISTORS
Q12/1 31-01015-03 2SA1015,SMD
Q44, Q45, Q47, Q302 31-01015-00 2SA1015 GR
Q11, Q21, Q43, Q46, Q48,
Q301, Q412, Q414, Q421,
Q424, Q425
31-01815-00 2SC1815
Q117, Q217 J31-00970-00 2SA970 GR
Q118, Q218, Q423 J31-02240-00 2SC2240
Q41, Q111, Q116, Q211,
Q216,Q413, Q422
31-02690-00 KSC2690AYSTU
Q42, Q110, Q210 31-01220-00 KSA1220AYSTU
Q112, Q212 J31-05171-00 2SC5171
Q113, Q213 J31-01930-00 2SA1930
CAPACITORS
C129,C132 26-68951-01
6.8pF, 50V,0805,NPO,
C1608C0G1H6R8D
C365 26-56051-01 56pJ,50V,0805,NPO
C31, C32, C33, C34, C35,
C36, C37, C38, C39, C310,
C311, C312, C313, C314,
C315, C316, C317, C318,
C363, C364
26-10151-00 100pF, 50V, 5%, NPO
C45, C46 05-22013-02 22pF, 1KV, ±5%
C366 05-56013-00
56pF, 1KV, ±5%,
DCH560J22SL
C112, C113, C212, C213 05-47113-00 470pF, 1KV, ±10%
C362 24-10312-00 10nF, 100V, ±20%
C120, C220 24-22312-04 22nF, 100V, ±10%
C3, C123, C223, C443 24-10412-01 0.1uF, 100V, ±20%
C432 24-22412-00 0.22uF, 100V, ±20%
C119, C219 25-22361-05 22nF, 63V, ±5%
C17, C27, C319, C320, C345,
C346, C411, C412, C444,
C448
25-10461-07 0.1uF, 63V, ±5%
C114, C115, C118, C214,
C215, C218
25-10461-01 0.1uF, 63V, ±10%
C121, C122, C221, C222 25-10561-02 1u, 63V ±5%
C421 06-47851-02 0.47uF, 50V, ±20%
C367 06-47921-00
CD110,4.7uF,25V,±
20%,F5.0
C11, C21 06-10051-08
CD11A,10uF, 50V, ±20%,
85ć
C41, C42, C48, C49, C128,
C228, C410, C415, C416,
C419, C425, C426, C428,
C429, C430, C431, C445,
C446, C447, C449, C450,
C12/1
06-10051-01
CD263(X),10uF,50V,±
20%,105ć,F5.0
C341, C342 06-47021-06
CD11A,47uF,25V,±
20%,F5.0
or 33-15609-12 / 21-
06101-00
ELECTRIAL PARTS LIST
PCB-1:MAIN BOARD 01-35601-00
Or D110 / D111
5.6V, 2W, 2EZ5.6D5-AP
zener / 10mm link
