NAD C 356BEE - Exploded View Parts List; Chassis and Transformer Parts; Front Panel and Knob Parts; Fastener Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001 66-185002-0 Chassis 1 F013 77-062001-1 LED Lens Bezel 1
C002 66-001004-1 Base Cover 1 77-062011-1 LED Lens Bezel Ti:1
C003 66-001010-0 Transformer Bracket 1 F014 76-062001-1 LED Lens 1
C004 67-091003-0 Shielding Box 1 F015 76-076001-0 IR Lens 1
C005 A18-35617-10 Main Transformer(AH) 1 F016 66-185001-0 Phone Bracket 1
A18-35617-20 Main Transformer(C) 1 F017 01-35607-00 Key Board 1
C006 66-001008-0 Trans Disc 1 F018 01-35603-00 Tone and Volume Board 1
C007 94-001004-2 Transformer label 1 F019 01-35604-00 Phone Board 1
C008 70-091004-2 Main Heatsink 1
C009 78-001004-0 Heat Conductive Pad 4
C010 66-001009-0 Clamper 2 R001 67-185001-0B Rear Panel AH AH:1
C011 69-091002-0 Spacer 1 67-185002-0B Rear Panel C C:1
C012 66-019004-0 PCB Support 2 1 R002 67-185003-0A Rear Panel Plate 1
C013 75-010004-1 Foot 4 R003 A17-07002-07 AC Inlet 1
C014 78-001002-0 Foot Pad 4 R004 A17-07002-10 AC Outlet AH:1
C015 01-35601-00 Main Board 1 R005 A11-01101-03 Rocker Switch 1
C016 01-35605-10 Power Board(AH) 1 R006 01-35609-00 RS232 Board 1
01-35605-20 Power Board(C) 1 R007 30-63200-00 Shorting Plug 2
F001 70-185001-1B Fascia 1
70-185011-1B Fascia Ti:1 T001 67-019004-8 Top Cover 1
F002 66-185003-0 Subfascia 1 67-038002-5 Top Cover Ti:1
F003 70-185003-0 End Cap L 1
70-185013-0 End Cap L Ti:1
F004 70-185004-0 End Cap R 1
70-185014-0 End Cap R Ti:1 S001 61-023206-0 Self Taping Screws BTB3×6 21
F005 73-014002-3 Volume Knob 1 S002 61-023106-0 Self Taping Screws STB3×6 41+2
73-020002-2 Volume Knob Ti:1 61-023106-1 Self Taping Screws STB3×6 Ti:2
F006 73-014001-2 Tone Knob 3 S003 61-023506-0 Machine Screws MB3×6 2
73-020001-1 Tone Knob Ti:3 S004 61-023108-0 Self Taping Screws STB3×8 4
F007 77-091003-3 Volume Knob Bezel 1 S005 61-023208-0 Self Taping Screws BTB3×8 23
77-091013-3 Volume Knob Bezel Ti:1 S006 61-073108-0 Self Taping Screws STO3×8 2
F008 77-185001-0 Tone Knob Bezel 1 S007 61-022204-6 Self Taping Screws BTB2.6×4 2
77-124011-1 Tone Knob Bezel Ti:1 S008 61-084108-0 Self Taping Screws STPW4X8 4+4
F009 77-132001-1 2P Input Button Bezel 5 61-084106-2 Self Taping Screws STPW4X6 Ti:4
77-132011-1 2P Input Button Bezel Ti:5 S009 61-224516-1
Hexagon Socket Head ScrewM4×16 2
F010 74-132001-0 Duo Button 5 S010 63-010408-0 Plain Washer 2
74-132011-0 Duo Button Ti:5 S011 63-020411-0 Spring Washer 2
F011 77-123004-1 Power Button Bezel 1 S012 64-108060-1 Hexagon Head Bolt,M8×60 1
77-123014-1 Power Button Bezel Ti:1 S013 63-010816-0 Washers 1
F012 74-123003-1 Power Button 1 S014 63-020820-0 Spring Washers 2
74-123013-1 Power Button Ti:1 S015 62-010802-0 Nut,M8 2
C356BEE EXPLODED VIEW PARTS LIST
