NAD C 422 User Manual

- 18 -
ELECTRICAL PARTS LIST
KEY ASSY
PC BOARD
PCB-N0A50C-KEY PCB ASSY KEY N0A50C
CAPACITOR
C201 157B-107M-5-KMK CE 6.3V 100µF 20% RL
C202 153F-103J-5-KM CM 50V 0.01µF 5% RL
COIL
L201 1801-220K-M COIL 22µH 10% AL BL7
WAFER/CONNECTOR
J202A 2101-1581-0 FLEXIBLE CONN. 35P
J204B 2102-021R-004 WAFER 2P P2.5 RIGHT
RESISTOR
R201 4701-681J-2 RCF 1/8W 680R 5% AT
R203,R204,R294 4701-122J-2 RCF 1/8W 1.2K 5% AT
R207 4701-182J-2 RCF 1/8W 1.8K 5% AT
R210 4701-222J-2 RCF 1/8W 2.2K 5% AT
R213 4701-472J-2 RCF 1/8W 4.7K 5% AT
R220,R221 4701-471J-2 RCF 1/8W 470R 5% AT
R222 4701-473J-2 RCF 1/8W 47K 5% AT
R233-R240,R247,R248,R291-R293 4701-103J-2 RCF 1/8W 10K 5% AT
R241-R246,R263-R272 4701-104J-2 RCF 1/8W 100K 5% AT
DIODE
D201 4804-1480-C DIODE 1N4148 ATS
D203 4837-5B61-2 DZ 1/2W 5.45-5.73 ROHM
SWITCH
M201,M204,M207,M210,M213,M216 5200-3538-0 SWITCH, TACT SKHHBY 7MM
M203,M206 5200-4721-0 TACT SWITCH (RIGHT
WIRE
J203A 7705-1150-2004 5P CONN WIRE ASSY L=150
J204A 7702-1075-2004 CONN.ASSY 2P P2.5 L=75
PC BOARD
0300 1725-080B-0100 PCB MAIN/KEY/VFD N0A50C
MISCELLANEOUS
0302 4154-2101-0 VFD HOLDER
0303 2460-1960-0 VFD, SAMSUNG,HNA-10SM12
