NAD C 422 User Manual

- 4 -
REAR PANEL / FRONT PANEL
REAR PANEL
FRONT PANEL
1. FM ANTENNA
2. AM ANTENNA
3. OUTPUT
4. IR IN
5. 12V TRIGGER IN
6. AC LINE CORD
1. POWER ON / OFF
2. POWER STATUS INDICATOR
3. BLEND
4. MEMORY
5. FM MUTE / MODE
6. AM / FM
7. DISPLAY
8. PRESET / TUNE
9. DISPLAY AREA
10. PRESET / TUNE CONTROL
' 2003 NAD C 422
OUTPUT
ANTENNA
GND
AM
FM
L
R
+12V TRIGGER
IN
IR
IN
6
34
5
1
2
PRESET / TUNE
MEMORY AM / FM DISPLAY
DELETE
BLEND
FM MUTE
/ MODE
PRESET
/ TUNE
© 2003 NAD C 422
PRESET
PRESET
PROGRAM
PROGRAM
FM MUTE
FM MUTE
BLEND
BLEND
TUNED
TUNED
FM ST
FM ST
RDS
RDS
ANTENNA
ANTENNA
34567
1
10
9
8
2
RDS Stereo Tuner C 422
IMPORTANT NOTES
1. Show the software version
Press “PRESET/TUNE” and “TUNE UP” ( ).
2. Light UP all the icon on the VFL
Press “PRESET/TUNE” and “TUNE DOWN” ( ).
3. CPU Resets
Press “PRESET/TUNE” and “TUNE DOWN” ( ) and any one key.
4. AM Step 10K/9K Change
Add D206: 10KHz / Delete D206: 9KHz.

NAD C 422 Specifications

General

Brand	NAD
Model	C 422
Category	Tuner
Language	English
