NAD C 422 - TRANSISTORS

- 23 -
TRANSISTOR
Q401,Q402 485A-950Y-5 TR 2SA950-Y HFE 100-200
Q403 4860-0050-5 TR SS8050 C/D SAMSUNG RL
Q702,Q703,Q902 4851-9230-5 TR 2SC1923-0 HFE 70-140
Q901 *CE 485C-945P-5 TR 2SC945P HFE 200-400
Q903,Q945,Q981 485A-114E-5 TR DTA114ESA ROHM
Q922,Q923,Q942 4860-1590-5 TR 2SC1740S
Q943,Q944 4860-8120-G TR 2SD1468S TPS ROHM
Q980,Q983,Q984 485C-114E-5 TR DTC114ES
Q982 4853-63BL-5 TR N-JEET 2SK-363BL
PC BOARD
1725-080B-0100 PCB MAIN/KEY/VFD N0A50C
MISCELLANEOUS
L903,L904 5600-3386-S COIL MPX LPF NMC-4085
L941 5600-3396-S COIL FM DET-1 10.7MHZ
L942 5600-3406-S COIL FM DET-2 10.7MHZ
L971 5600-3280-G COIL MW RF BLOCK
L972 5600-3416-S COIL AM IFT NMIF-4062
M219 2703-0200-0 CR 6MHZ CSTLA6M00G55-A0
R801A *AH 4132-1061-0 SOLDER TAG
TUNER 4131-7701-0 ANTENNA WASHER
Reference No. Part No. Description
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film.
