NAD C 541i User Manual

21
1 3 2
M313 IR_IN
3 2
1
U601A LM393
C605
680P
L601 27mH
R611 100K
R606 1K5
5 6
7
U601B LM393
R604 1K8
R605 10K
4 8
U601C LM393
C606 104K
C609 100u/10V
1 2 3 4 5
J602A
RMO
Q602 2SC1923
Q603 2SC1923
R622
10K
R623
10K
R614 202K
R615 10K
C607 100P
DGND REM_IN D+5V IR DGND
R603 10K
R609 10K
R631B 220 R631A 220
REMOTE
NOTE: 1. RESISTORS, ARE CARBON FILM 5% 1/8W UNLESS
OTHERWISE SPECIFIED.
2. CERAMIC CAPACITORS, ARE 50V 10%. UNLESS
OTHERWISE SPECIFIED.

NAD C 541i Specifications

General

Brand	NAD
Model	C 541i
Category	CD Player
Language	English
