NAD C 541i - MECHANISM PARTS LIST

35
1 4102-9000-0 Outside Main Chassis 1
2 4102-9001-0 Tray 1
3 4102-9002-0 Subchassis 1
4 4102-9003-0 Chucking Plate 1
5 4102-9004-0 Drive Gear 1
6 4102-9005-0 Control Cam 1
7 4102-9006-0 Chucking Pulley 1
8 4102-9007-0 Gear Cover 1
9 4102-9008-0 Tray Gear 1
10 4102-9009-0 Intermediate Gear 1
11 4102-9010-0 Loading Pulley 1
12 4102-9011-0 Motor Pulley 1
13 4102-9012-0 SW Pin 1
14 4102-9013-0 Chucking Yoke 1
15 4102-9014-0 Optical Pickup Unit 1
16 4102-9015-0 Loading PWB 1
17 4102-9016-0 Motor RF-500TB-14415 1
18 4102-9017-0 Leaf Switch 1
19 4102-9018-0 Connector pin (5P) 1
20 4102-9019-0 Magnet 1
21 4102-9020-0 Insulator 4
22 4102-9021-0 Coil Spring (Front) 2
23 4102-9022-0 Coil Spring (Rear) 2
24 4102-9023-0 Screw-Motor M2.6x2.5 2
25 4102-9024-0 Screw M2.6x7 2
26 4102-9025-0 Screw Washer Based M2.6x16 4
27 4102-9026-0 Rubber Belt 1
28 4102-9027-0 Center Ring 1
29 4102-9028-0 Turn Table 1
30 4102-9029-0 Gear (A) 1
31 4102-9030-0 Motor Gear 1
32 4102-9031-0 Damper 1
MECHANISM EXPLODED VIEW PARTS LIST
Item Part No. Description Qty
