NAD C3050 - General Specifications; Dimensions and Weight

ENGLISH
14
GENERAL SPECIFICATIONS
MAIN IN, SPEAKER OUT
Continuous output power into 8 ohms and 4 ohms 100W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
THD (20 Hz – 20 kHz) <0.03% (250 mW to 100 W, 8 ohms and 4 ohms)
Signal-to-Noise Ratio >95dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power >115 W (at 1 kHz 0.1 % THD)
IHF dynamic power
8 ohms: 180 W
4 ohms: 250W
2 ohms: 300 W
Peak output current >20A (in 1 ohm, 1 ms)
Frequency response ±0.3 dB (20 Hz - 20 kHz)
Channel separation
>75dB (1 kHz)
>70dB (10 kHz)
Input sensitivity (for 100 W in 8 ohms)
540 mV
Digital: -6dBFS
Power consumption
• at Auto Standby ON and Network Standby OFF
• at Auto Standby ON and Network Standby ON
• OFF mode (Power switched OFF)
0.5 W*
2.0 W**
0.1 W
DIMENSION AND WEIGHT
Gross dimensions (W x H x D) ****
435 x 110 x 355mm
17 1/4 x 4 3/8 x 14 inches
Net weight 10 kg (22 lbs)
Shipping weight 12.6 kg (27.8 lbs)
* - After 20 minutes of no user interface interaction and no active source input
** - With established wired or wireless network connection, wireless Bluetooth connectivity and no user interface interaction and no active source input for 15 minutes
*** - Applicable when optional MDC2 BluOS D is installed. Supported services may vary over time. Inquire via support.bluos.net for updated list
**** - Gross dimension includes feet, volume knob and extended front and rear panel terminals.
Specifications are subject to change without notice. For updated documentation and features, please check out www.NADelectronics.com for the latest information about C 3050.
REFERENCE
SPECIFICATIONS
