NAD C446 - Electrical Parts List

PCB ASSEMBLY A16-44601-22 Ｃ446 MAIN ＰＣＢ ｗ／ｏ ｐａｒｔｓ
RESISTOR
R415, R652, R668, R1000, R1001,R1002,
R1003
07-90000-00 0Ω, 0603, ±5%,RC0603JR-070RL
R636 07-90339-00 3.3Ω,0603,1/10W,±5%,RC0603JR-073R3L
R667, R679, R680,R681, R682 07-91009-00 10Ω,0603,1/10W,±1%,RC0603FR-0710RL
R401, R402, R403,R405, R407, R411,R412,
R413, R414,R640, R645, R648, R649, R673,
R419,R420, R422, R424,R428, R431
07-90330-00 33Ω,0603,1/10W,±5%,RC0603JR-0733RL
R605, R621,R607, R623 07-90470-00 47Ω,0603,1/10W,±5%,RC0603JR-0747RL
R421, R426,R433, R435 07-94999-00
49.9Ω,0603,1/10W,±1%,RC0603FR-
0749R9L
R609, R614 07-90820-00 82Ω,0603,1/10W,±5%,RC0603JR-0782RL
R684 07-90101-00
100Ω,0603,1/10W,±5%,RC0603JR-
07100RL
R643, R646, R647, R655, R656 07-90121-00
120Ω,0603,1/10W,±5%,RC0603JR-
07120RL
R608, R683, R685 07-90331-00
330Ω,0603,1/10W,±5%,RC0603JR-
07330RL
R437, R438 07-90471-00
470Ω,0603,1/10W,±5%,RC0603JR-
07470RL
R143, R606,R622, R676 07-91001-00 1KΩ,0603,1/10W,±1%,RC0603FR-071KL
R140 07-90202-00 2KΩ,0603,1/10W,±5%,RC0603JR-072KL
R677 07-90222-00 2.2KΩ,0603,1/10W,±5%,RC0603JR-072K2L
R434 07-93011-00
3.01KΩ,0603,1/10W,±1%,RC0603FR-
073K01L
R425 07-93241-00
3.24KΩ,1/10W,±1%,0603,RC0603FR-
073K24L
R651, R653, R654, R66, R1345, R1348 07-90472-00
4.7KΩ,0603,1/10W,±5%,RC0603JR-
074K7L
R436, R631, R635, R637, R642, R644, R678,
R409, R61, R62, R64, R1355
07-90103-00 10KΩ,0603,1/10W,±5%,RC0603JR-0710KL
R418 07-91022-00
10.2KΩ,0603,1/10W,±1%,RC0603FR-
0710K2L
R1352 07-90123-00 12KΩ,0603,1/10W,±5%,RC0603JR-0712KL
R406 07-91402-00 14KΩ,0603,1/10W,±1%,RC0603FR-0714KL
R602, R610, R618, R624, 07-90183-00 18KΩ,0603,1/10W,±5%,RC0603JR-0718KL
R632, R641, R141 07-90203-00 20KΩ,0603,1/10W,±5%,RC0603JR-0720KL
R601, R615, R617, R628 07-92102-00 21KΩ,0603,1/10W,±1%,RC0603FR-0721KL
R616, R629 07-90223-00 22KΩ,0603,1/10W,±5%,RC0603JR-0722KL
ELECTRICAL PARTS LIST
MAIN ＢＯＡＲＤ ＡＳＳＹ．（ＡＨ－Ｖｅｒｓｉｏｎ ０１－４４６０１－９８）（Ｃ－Ｖｅｒｓｉｏｎ ０１－４４６０１－９９） ｗ／ｏ Ｍｅｄｉａ Ｍｏｄｕｌｅｅ
Page 21
