NAD C446 Service Manual

REAR PANEL / FRONT PANEL VIEW
FRONT PANEL
REAR PANEL
Internet Radio
Magic 89.9
Playing
© NAD C 446
Digital Media Tuner C 446
SOURCE PLAY/PAUSE INFO SETUP BACK
CONTROL/ENTER
3 4 5 6 7 8 9 101 2
11
© NAD C 446
FM
ANTENNA
GND AM
DAB
AUDIO OUT
DIGITAL OUT
LAN RS232
MP DOCK
+12V
TRIGGER
IN
POWER
100~240V – 50/60Hz
ON
IR IN
DATA PORT
L
R
WIFI
3 4 5 6 7 8 9 11101 2
12
1
FM ANTENNA TERMINAL
AM ANTENNA TERMINAL
2 DAB ANTENNA TERMINAL (230V version model only)
3 AUDIO OUT
4 DIGITAL OUT
5 LOCAL AREA NETWORK (LAN) PORT
6 WIRELESS (WIFI) ANTENNA TERMINAL
7 RS 232
8 MP DOCK
9 +12V TRIGGER IN
10 IR IN
11 POWER
12
AC MAINS INPUT
1 STANDBY BUTTON
2 STANDBY LED
3  SOURCE 
4 PLAY/PAUSE
5 INFO
6
REMOTE SENSOR
7 VACUUM FLUORESCENT DISPLAY (VFD)
8 USB
9 SETUP
10 BACK
11
CONTROL/ENTER
Page 5
