NAD C446 - Page 29

J901 13-23903-01 VH 3.96A-3A
J902 13-22510-00 XHB 2.5A-10A
S902 70-223002-0 AL1050 T5,T=3.0mm
S901, S903 70-019005-1 6063 T5, BLACK
MISC
Rocker Switch A11-01101-03 RF-1003-BB2, 10A 250V, TV-5
Description
P/N
C446 Titanium tuning knob. J71-223011-0
C446 Graphite tuning knob. J71-223001-0
C446 AH Rear panel. 67-223004-2C
C446 C rear panel. 67-223005-4C
C446 CT rear panel. 67-223005-4C
C446 Titanium top panel. 67-223013-1
C446 Graphite top panel. 67-223003-1
C446 Bottom chassis. 67-223001-3
C446 Subfacia. 67-223002-3
Cables
FFC from front PCB to main PCB 24 pins same side. 14-44624-00
FFC from main PCB to Tuner module 17 pins opposite side. 14-98017-10
Ribbon cable 10 pins SMPS to the main board. 14-44610-00
Ribbon cable 4 pins encoder PCB to front panel PCB. 14-44604-01
Ribbon cable 4 pins from main PCB to USB connector. 14-44604-00
Gold WiFi connector and cable for WiFi antenna. 29-44600-00
PCB Assemblies
C446 C/CT main assembly programmed for C/CT-units includes media module 01-44601-20
C446 AH main assembly programmed for AH-units includes media module 01-44601-10
C446 AH/C SMPS power supply assembly 01-44603-00
C446 Front Panel Keyboard with VFD attached. 01-44602-00
C446 Encoder assembly (pcb # 16-44604-21). 01-44604-00
C446 C/CT media module J37-20262-01
C446 C/CT DAB connector. 17-05001-09
C446 AH media module without DAB connector. J37-20262-00
Accessories
TNR 2 remote control J30-14460-00
DAB antenna “telescoping” 29-80106-00
WiFi antenna 30-34702-00
C446 Carton C Graphite 88-223001-0A
EPE End Cap RIGHT C446 89-223002-0
EPE End Cap LEFT C446 89-223001-0
MAJOR ASSEMBLIES AND COSMETICS
Page 29
