NAD M2 User Manual

EXAMPLE ILLUSTRATION OF GROUNDING THE M2
VIA THE REAR PANEL GROUND TERMINAL
NOTES
• TheaboveillustrationshowstheM2beingconnectedtogroundvia
a metal water pipe. There maybe other grounding conductor points
in your home. Consult with a licensed electrician to properly locate
or correctly install a grounding conductor in your home. NAD is not
responsible for any malfunction, damage or costs associated with the
installation, connection or grounding of your M2.
• ThegroundingwireisnotsuppliedwithyourM2.
DIGITAL POWERDRIVE
The M2 uses NAD’s proprietary Digital PowerDrive™ amplier technology
that allows substantial additional power for short periods of time. Research
has shown that the peak to average power required to faithfully reproduce
music can be a factor of ten for well recorded performances. Digital
PowerDrive uniquely satises this requirement. Music sounds more
dynamic and “open” with PowerDrive because the musical transients that are
present in a live performance are not reduced in amplitude or “compressed”.
IDENTIFICATION OF CONTROLS
REAR PANEL
10
ENGLISH FRANÇAIS ESPAÑOL ITALIANO DEUTSCH NEDERLANDS SVENSKA РУССКИЙ

NAD M2 Specifications

General

Amplifier class	-
Frequency range	20 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	250 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	0.004 %
AC (power) in	Yes
Purpose	Home
Product color	Silver
Connectivity technology	Wired
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Package weight	25600 g

Weight and Dimensions

Depth	502 mm
Width	435 mm
Height	148 mm
Weight	20200 g
