NAD T 761 - Exploded View Parts List; Exploded View Item List

77
EXPLODED VIEW PARTS LIST
ITEM Part No. Description
Qty
0101 1403-5160-1 BOTTOM CHASSIS (T-760) 1
0102 *AH 1403-6390-0 REAR PANEL T-761 (AH) 1
0102 *C 1403-6391-0 REAR PANEL T-761(C) 1
0103 *AH 1403-5181-0 TOP COVER T-761 1
0103 *C 1403-5182-0 TOP COVER T-761 1
0104 1403-6510-0 SUB-FASCIA T-761 1
0105 *AH, *C 1403-6380-0 FASCIA T-761 1
0106 4152-7830-0 FRONT INPUT BEZEL T-761 1
0107 4134-9031-0 BRACKET SURR BOARD T-760 1
0108 4134-9041-0 BRACKET AC3 BOARD T-760 1
0109 4134-9051-0 BRACKET ANGLE 2
0110 4134-9061-0 BRACKET PHONES 1
0111 4134-9071-0 BRACKET PCB MOUNTING 5
0112 4154-0311-0 DUMMY CLAMP 1
0113 2444-1601-0 POWER BUTTON GREEN LONG 1
0114 3716-4401-0 WINDOW LENS 1
0116 4152-4341-0 INPUT BUTTON LOZENGE 1
0119 2444-1901-0 DUO BUTTON T-760 1
0120 2444-1301-1 BUTTON RACKER (NICKEL) 1
0121 4154-0091-0 BEZEL RACKER (NICKEL) 1
0122 2444-2101-0 INPUT BUTTON 4
0123 4154-0411-0 BEZEL DUO 1
0124 4134-9081-0 VOLUME KNOB SKIN T-760 1
0125 4154-0341-0 VOLUME KNOB CORE T-760 1
0126 4152-4631-0 RUBBER FOOT (522) 14MM HIGH 4
0127 4152-4641-0 CUSHION FOOT (522) 4
0128 4152-4331-0 POWER BUTTON BEZEL 1
0129 4152-7900-0 VIDEO COVER T-761 1
0130 4152-1701-0 LED BEZEL (117) 0
0131 3714-5706-0 LED LENS (412) CLEAR SAN 1
0132 8900-3040-1 DC FAN 12V 80x80mm L=230MM 1
0133 4152-3851-0 SQ. STRAIN RELIEF BUSING 1
0134 *AH 7009-3100-2 AC CORD 18AWGX2 1
0134 *C 7009-3110-0 AC CORD (SEMKO) 1
0136 5400-9051-0 HEATSINK T-760 1
0137 4134-0121-0 HEATSINK MOUNTING BRACKET 2
0138 4152-0451-0 L-BRACKET 2
0139 2600-4008-0973 FLAT WASHER M4X0.8X9.7 BZ 4
0140 2607-4010-0703 SPRING WASHER M4X1X7 BZ 4
0141 2904-4010-3000 SCREW M4X10 (BLK) 4
0143 2842-3367-0 METAL WASHER ID=3.3 OD=6.7 4
0144 2900-4006-3010 M4X0.5PX6MM W/FLAT WASHER 6
0145 2954-3008-3000 T3X8MM SELF TAPPING 37
0146 2904-3008-0000 M3X8MM BINDING HEAD (YEL.ZN) 2
