NAD T 761 - Electrical Parts List

53
ELECTRICAL PARTS LIST
Reference No. Part No. Description
AC3 BOARD
PC BOARD
0001 PCB-N0950C-AC3 AC3 ASSEMBLY
CAPACITORS
C101, C103 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C102 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C104 157C-108M-5-S5 CE 10V 1000µF 20% RL 10x16
C105 150F-103K-J-BD CC 50V 0.01µF 10% 0805
C106, C108 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C107 157D-228M-5-W9 CE 16V 2200µF 20% RL 12x20
C1101, C1104 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1102, C1105 15FF-224Z-J-BD CC 50V 0.22µF +80/-20% 0805
C1106, C1107 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C1112-C1114, C1122 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C1123, C1131, C1132 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C1134, C1136, C1137 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C1115 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C1116 157E-105M-5-EI CE 25V 1µF 20% RL 3x5
C1117 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1118 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C1119-C1121 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C1135 150F-100J-J-BD CC 50V 10pF 5% 0805
C114, C115 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C117, C119 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C120, C121 157D-226M-5-GM CE 16V 22µF 20% RL 4x7
C122, C123 150F-562J-J-BD CC 50V 5600pF 5% 0805
C125 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C126 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C127 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C128 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C129 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C132, C134 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C135, C136 150F-562J-J-BD CC 50V 5600pF 5% 0805
C138 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C139 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C140 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C141 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C142 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C143 157E-105M-5-EI CE 25V 1µF 20% RL 3x5
C145, C147 157D-475M-5-EI CE 16V 4.7µF 20% RL 3x5
C148 150F-562J-J-BD CC 50V 5600pF 5% 0805
C149, C152 150F-103K-J-BD CC 50V 0.01µF 10% 0805
C150, C151, C157 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C156 150F-683M-J-BD CC 50V 0.068µF 20% 0805
C158 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C159 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C161, C162 15FD-105Z-J-BD CC 16V 1µF +80/-20% 0805
C165 157D-225M-5-GM CE 16V 2.2µF 20% RL 4x7
C166, C167, C169 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C168 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C1102, C1105 15FF-224Z-J-BD CC 50V 0.22µF +80/-20% 0805
C172 153F-225J-5-TOM CM 50V 2.2µF RL 10X8 METALLIZED
C173 157C-107M-5-IU CE 10V 100µF 20% RL 5x11
