NAD T 761 - Page 44

54
C174 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C175 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C176 157C-107M-5-IU CE 10V 100µF 20% RL 5x11
C179-C180, C183-C184 150F-104M-J-BD CC 50V 0.1µF 20% 0805
C199 157D-106M-5-GM CE 16V 10µF 20% RL 4x7
C181 150E-104M-J-BD CC 25V 0.1µF 20% 0805
C182 150F-103K-J-BD CC 50V 0.01µF 10% 0805
C193, C194, C198 150F-104M-J-BD CC 50V 0.1µF 20% 0805
DIODE
D101 4840-0490-0 BRIDGE RECTIFIER RB152 100V 105A
HEATSINKS
H-U121 5400-0831-0 HEATSINK (214) 20MM-HIGH HOLE
H-U123 5400-9130-0 HEAT SINK FOR 7805 2438-17
COILS
L101-L104 1801-100K-M COIL 10µH 10% BL7.0
CRYSTAL
M101 2300-3060-0 X'TAL 12.288MHZ +/-20PPM HCMOS/TTL OSCILLA
TOR
TRANSISTOR
Q101 485C-114E-5 TR DTC114ES
RESISTORS
R101-R103 4720-103J-J RMG 1/10W 10K 5% 0805
R104 4720-680J-J RMG 1/10W 68R 5% 0805
R105-R109 4720-103J-J RMG 1/10W 10K 5% 0805
R110 4707-103C-5-8 RCFA 1/2W 10K 2% RL 8 9P SIP 4609X-101-103
R1100 4720-750J-J RMG 1/10W 75R 5% 0805
R1101 4720-473J-J RMG 1/10W 47K 5% 0805
R111, R112 4720-103J-J RMG 1/10W 10K 5% 0805
R113 4720-473J-J RMG 1/10W 47K 5% 0805
R115 4720-750J-J RMG 1/10W 75R 5% 0805
R116 4720-473J-J RMG 1/10W 47K 5% 0805
R118 4720-750J-J RMG 1/10W 75R 5% 0805
R119 4720-000J-J RMG 1/10W 0R 5% 0805
R122 4720-151J-J RMG 1/10W 150R 5% 0805
R123 4720-103J-J RMG 1/10W 10K 5% 0805
R125 4720-151J-J RMG 1/10W 150R 5% 0805
R126 4720-103J-J RMG 1/10W 10K 5% 0805
R127 4720-104J-J RMG 1/10W 100K 5% 0805
R129 4720-000J-J RMG 1/10W 0R 5% 0805
R130 4720-151J-J RMG 1/10W 150R 5% 0805
R131 4720-103J-J RMG 1/10W 10K 5% 0805
R133 4720-151J-J RMG 1/10W 150R 5% 0805
R134 4720-103J-J RMG 1/10W 10K 5% 0805
R135, R136 4720-102J-J RMG 1/10W 1K 5% 0805
R137 4720-151J-J RMG 1/10W 150R 5% 0805
R138 4720-103J-J RMG 1/10W 10K 5% 0805
R139 4720-102J-J RMG 1/10W 1K 5% 0805
R140 4720-101J-J RMG 1/10W 100R 5% 0805
R150 4720-151J-J RMG 1/10W 150R 5% 0805
R155 4720-153J-J RMG 1/10W 15K 5% 0805
R156, R157 4720-103J-J RMG 1/10W 10K 5% 0805
R158 4720-151J-J RMG 1/10W 150R 5% 0805
R159 4720-153J-J RMG 1/10W 15K 5% 0805
R160, R161 4720-103J-J RMG 1/10W 10K 5% 0805
Reference No. Part No. Description
