NAD T 761 - Page 45

55
R162 4720-151J-J RMG 1/10W 150R 5% 0805
R163, R164 4720-223J-J RMG 1/10W 22K 5% 0805
R165 4720-121J-J RMG 1/10W 120R 5% 0805
R166 4720-201J-J RMG 1/10W 200R 5% 0805
R167, R168 4720-103J-J RMG 1/10W 10K 5% 0805
R169 4720-102J-J RMG 1/10W 1K 5% 0805
R171 4720-103J-J RMG 1/10W 10K 5% 0805
R172 4720-471J-J RMG 1/10W 470R 5% 0805
R173 4720-103J-J RMG 1/10W 10K 5% 0805
R181 4720-000J-J RMG 1/10W 0R 5% 0805
R184, R185 4720-104J-J RMG 1/10W 100K 5% 0805
R186, R189 4720-000J-J RMG 1/10W 0R 5% 0805
R190-R192 4720-104J-J RMG 1/10W 100K 5% 0805
R193 4720-000J-J RMG 1/10W 0R 5% 0805
R194 4720-335J-J RMG 1/10W 3.3M 5% 0805
ICs
U101 3131-7230-0 IC 74HC151 QUAD 4-PIN MUX SOP16 SMD
U102 3131-3870-0 IC 74HC157 QUAD 2-INPUT MUX SO16
U103 3131-3700-0 IC CS5331A 18BIT A/D CONVERTER CRYSTAL
U104 3130-9560-0 NJM5532 IC 'DIP8'
U105 3131-3720-0 IC CS4926 DSP CRYSTAL
U106, U107 3130-8980-0 IC 74HC574 8X D-TYPE LATCHES
U108 3131-9320-0 IC AT27C020-70 256Kx8
U109 3130-9560-0 NJM5532 IC 'DIP8'
U110 3130-8890-0 IC CS8414 DIR 96KHZ 24BIT
U111-U113 3131-3710-0 IC CS4340 D/A CONVERTER CRYSTAL
U114 3131-9100-0 IC 74HCU04 HEX INVERTERS (SOP)
U115 3130-6590-0 IC 74HC74 DUAL D-TYPE FLIP-FLOP
U116 3130-9560-0 NJM5532 IC 'DIP8'
U117 3130-6590-0 IC 74HC74 DUAL D-TYPE
U118, U119 3131-9050-0 IC 74HC00 QUAD 2I/P NAND GATE SOP
U120 3130-6590-0 IC 74HC74 DUAL D-TYPE
U121 3130-5610-0 IC LM317T+ADJ REGULATOR
U123, U125 3130-2020-2 IC 7805 REG 5V
U131, U134 3130-9560-0 NJM5532 IC 'DIP8'
FRONT
AMP BOARD
PC BOARD
0002 PCB-N0950C-AMP1 POWER AMP L/R/C ASSEMBLY
CAPACITORS
C501, C502 157D-476M-5-IM CE 16V 47µF 20% RL 5x7
C503, C504 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C505, C506 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C507-C510 157F-106M-5-IU CE 50V 10µF 20% RL 5x11
C511, C512 150F-070D-5-GG CC 50V 7pF 0.5pF RL 4x4
C513, C514 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C515, C516 150F-181K-5-GG CC 50V 180pF 10% RL 4x4
C517, C518 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
C519, C520 153F-104J-5-QUN CM 50V 0.1µF RL (9X11) POLYESTER
C521, C522 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
C523, C524 15CH-020C-5-GG CTC 0/60 2pF 0.25pF RL 4x4
C525, C526 157I-477M-5-X& CE 63V 470µF 20% RL 12.5x25
C538 150F-223Z-5-UG CC 50V 0.022µF +80/-20%
C541, C542 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C543 15CH-020C-5-GG CTC 0/60 2pF 0.25pF RL 4x4
C544 150F-181K-5-GG CC 50V 180pF 10% RL 4x4
C545 157D-227M-5-KW CE 16V 220µF 20% RL 6x12
C546 157D-476M-5-IU CE 16V 47µF 20% RL 5x11
Reference No. Part No. Description
