NAIM NAIT5 - Page 8

nait 5 connected to power supply
mains input
power
to left loudspeaker
ch1
to right loudspeaker
ch2
+ - - +
input
signal
out A
signal
out B cdtunertapeA/VAUX 1AUX 2
mains inputpower
flatcap 2 power supply
cable
direction
marker
4 to 4 pin DIN
5 to5 pin DIN
Interconnect Cables
7
signal
out A
power
out A
signal
out B
signal
out C
signal
out D
for CD5, Headline
or Stageline
(additional
interconnects
required)
link plug fitted
