NAIM SUPERNAIT 3 - Controls and Connections E10

E10
NAIT XS 3
9. Controls and Connections
9.1 Front Panel Controls
Note: Icon descriptions can be found on Section 16.
9.2 Rear Panel Connections
Note: Icon descriptions can be found on Section 16.
ch1
-ve
nc
nc
ch2
cd and tuner in
ch1
-ve
ch1
(out)
ch2
(out)
ch2
av and stream
in/out
+ve
-ve
+ve
ch1
ch2
aux 2 in
Note: The link plug should be removed only if a power
supply upgrade is to be used, an alternative preamplier
is to use the NAIT XS 3 power amplier section, or an
alternative power amplier is to use the NAIT XS 3
preamplier section. It should remain tted in all other
circumstances.
Note: The NAIT XS 3 features various technologies to
reduce microphonic eects. Some movement of the board
and sockets when connecting and disconnecting cables is
normal.
ch2
ch1
+ve
-ve
power amp in
+ve
-ve
+ve
ch1
ch2
preamp out
DIN:
Phono:
DIN + Phono:
