Installation Warnings / Play Zone for Installation
- Must be performed by a technician -
3-3 Play Zone for Installation
Create a play zone around the machine so that players do not bump into bystanders or passersby.
Leave a space of 1 m or more between the machine and the wall or other machines
so that parts can be removed when performing service work.
A ceiling height of 2 m 65 cm or more is required.
1 m or more
1 m or more
1 m
or more
1 m
or more
Play zone
3 m 10 cm or more
3 m 10 cm or more
