NANO D2 - Product Dimensions and Weight

7
heatless desiccant air dryer
D2
2.2 product dimensions
model
dimension
weight
A B C D E
mm inches mm inches mm inches mm inches mm inches kg lbs
NDL
-060 743 29.25
426 16.77 283 11.14 234 9.21
681 26.81 47.0 104
NDL
-070 743 29.25 681 26.81 47.0 104
NDL
-080 923 36.34 861 33.90 58.0 128
NDL
-090 923 36.34 861 33.90 58.0 128
NDL
-100 1098 43.23 1036 40.79 70.5 155
NDL
-110 1248 49.13 1186 46.69 82.5 182
NDL
-120 1498 58.97 1436 56.53 95.5 210
NDL
-130 1848 72.75 1786 70.31 117.5 259
DIMENSION 'A'
DIMENSION 'B'
DIMENSION 'C'
INLET
DIMENSION 'D'
OUTLET
DIMENSION 'E'
