6 StarLink
™
Connect SLECDMA-CB Series Alarm Communicators -- Installation Instructions
NOC Originated
Alarms
Contact ID
Event Data
Sent
Pulse Format
Event Code
Sent
Initiated By Comments
Supervisory Fail
E356 A00 Zn000 99
Automatically by NOC if fail to receive
any signal from StarLink radio within
Supervisory Timeout duration.
For Auto Enroll, uses captured telephone
number, Sub ID and format. For Dealer
Programmed, uses entered telephone
number, Sub ID and format.
Press to Send
Test Signal
E601 A00 Zn000 98
Manually by dealer from the Manage-
ment Center Signal Log screen (located
at http://NapcoNoc2.com). Sends test
into CS receiver.
Same comment as above.
Press to Send
Radio Test
Not Applicable
Nothing sent to
CS receiver
Not Applicable
Manually by dealer from the Manage-
ment Center Checkins screen (located at
http://NapcoNoc2.com). Sends a com-
mand to the StarLink radio to force a
check-in to the NOC.
----
SIGNALS ORIGINATED AT THE NOC
STARLINK RADIO RELATED EVENT
REPORT CODES (Contact ID by default)
EVENT AREA
CONTACT ID
PULSE
4/2
CODE ZONE #
IN 1 Fire
0 E110 990 1A
IN 2 Panic
0 E120 992 22
IN 3 Trouble
0 E300 993 F3
Low Battery/Voltage
0 E302 994 F4
Tamper Trouble
0 E341 995 F5
Reboot
0 E625 997 F7
IN 1 CO (Carbon Monoxide)
0 E162 998 18
Panic Alarm*
E123
Holdup Alarm*
E122
Medical Alarm*
E100
24 hour Aux. Alarm*
E150
24 hour Aux. Restore*
R150
Burg Perimeter Alarm*
E131
Burg Interior Alarm*
E132
Keypad Holdup Alarm (ambush)*
E121
Keypad Panic Alarm*
E123
Keypad Emergency Alarm*
E140
Opening*
E401
Closing*
R401
A.C. Trouble*
E301
Tel 1 Fail*
E351
Fire Polling Report
E780 999 F9
Supv Failure Report
E788 000 D1 or D2
Tip/Ring Wiring Fault Report
E789 000 F2
Path Test Report
E602 890 77
*Not generated by the StarLink radio.
JUMPER DESCRIPTIONS
Jumper block labeled "X5"; from top to bottom, as
detailed in the following table. Note: Contact ID is
always available in response to a Contact ID
handshake.
The SLE series radios are compatible with 4/2 Pulse
Dialing formats with 10pps, 20pps, and 40pps with and
without checksum, either 1400Hz or 2300Hz
handshake / kissoff. See page 15 for table of formats.
Refer to WI2140 for selecting the required handshake /
kissoff frequency in the NOC (http://NapcoNoc2.com)
setup screens (as required by the control panel).
Jumper Block "X5" Options
Jumper block labeled "X5" contains 5 jumper terminals; from top
(labeled "1") to bottom (labeled "5") as follows:
Jumper ON
Jumper
Number
Jumper OFF
Not used; do NOT install jumper 1 Not used; do NOT install jumper
4/2 with Checksum Pulse Format 2
Contact ID or 4/2 format without
sum check
Not used; do NOT install jumper 3 Not used; do NOT install jumper
10K EOLR Required 4
IN3 no EOLR (normally high, active
low trigger)
10K EOLR Required 5
IN2 no EOLR (normally high, active
low trigger)
