1. Fit the side burner frame into the opening. The frame should be attached to the opening to prevent any future movement (fasten-
ers not included).
2. Ensure that there is at least 5 sq in of opening in the bottom of the cut out, for combustion air.
3. Set the side burner into the frame.
4. Connect the gas supply to the side burner valve. Leak test the entire installation before operating the unit.
4. BUILT-IN SIDE BURNER INSTRUCTIONS
N280-0003P (BLACK)
N280-0004 (STN STL)
