ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED
MKGK / MKGB / MKGR
MKGA / MKGC / MKGT
GI-RB
MEGK / MEGB / MEGR
MEGA / MEGT
GI83
GI85
07.07.14
REF. NO PART NUMBER DESCRIPTION 1 W475-0797 NEWPORT LEFT SIDE BRICK PANEL (GI83) 2 W475-0799 NEWPORT REAR BRICK PANEL (GI83) 3 W475-0798 NEWPORT RIGHT SIDE BRICK PANEL (GI83) 4 W475-0815 OLD ENGLISH LEFT SIDE BRICK PANEL (GI85) 5 W475-0813 OLD ENGLISH REAR BRICK PANEL (GI85) 6 W475-0814 OLD ENGLISH RIGHT SIDE BRICK PANEL (GI85) 7 8 9
I3FS6 SMALL PREMIUM SCALLOPED FRAME
10
I3FS9 LARGE PREMIUM SCALLOPED FRAME
REF. NO PART NUMBER DESCRIPTION 11
W715-0561 HEARTH TRIM (GI-RB)
12
W525-0022 RAILS (X2) (GI-RB)
13
XI3BK BLOWER KIT
14
GLASS MEDIA MEDIA KIT (VARIOUS COLOURS)
GLASS MEDIA MEDIA ENHANCEMENT KIT (VARIOUS COLOURS)
W660-0081 WALL MOUNTED THERMOSTAT
4
1
5
2
6
3
4
1
5
2
6
3
I3FS6 I3FS9
