Napoleon IR3GN - 12 Valve Train Assembly

33
W415-1355 / 10.01.14
EN
5 7
2
8 189 12 13 1510
43
1611 146 17
1
5 7
2
8 1910 13 14 1611
43
1712 156 18
1
ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED
07.07.14
VALVE TRAIN ASSEMBLY
W175-0342
REF. NO. PART NUMBER DESCRIPTION 1 W175-0342 LP CONVERSION KIT 2 W010-2705 TUBE BURNER ASSEMBLY 3 W080-1305 PILOT GROUND BRACKET 4 W010-2763 PILOT ASSEMBLY 5 W080-1194 BURNER BRACKET (X2) 6 W255-0002 3/8" TUBE TO 1/8" NPT PIPE 7 W080-1189 ORIFICE BRACKET 8 W456-0042 BURNER ORIFICE #42 (NG) 9 10
REF. NO. PART NUMBER DESCRIPTION 11 12 13 14 15 16 17 18
89
19
W290-0180 BURNER TRAY GASKET W500-0610 SECURING PLATE N255-0002 BULKHEAD FITTING W585-0749 HEAT SHIELD W080-1186 VALVE BRACKET W190-0029
CONTROL BOARD
W725-0056 VALVE W010-1985 WIRE HARNESS ASSEMBLY
W080-1193
PILOT BRACKET
W710-0050 BURNER TRAY W456-0053 BURNER ORIFICE #53 (LP)
12.0 VALVE TRAIN ASSEMBLY
