Propane Cylinder Installaon
: Ensure that the gas regulator hose is kink free. Remove the cap or plug from
the cylinder fuel valve. Insert the black QCC1 regulator nipple onto the QCC1 fuel valve. Hand ghten
clockwise. Do not use tools. Leak test all joints prior to using the barbecue. A leak test must be performed
annually, and each me a cylinder is hooked up, or if a part of the gas system is replaced.
• Check that the cylinder valve is closed by turning the knob clockwise.
• Check that the grill’s burner knobs are in the o posion.
• Open cabinet doors.
• Place the cylinder into the tank holder in boom of shelf.
• Posion the cylinder so that the valve faces toward the front of the unit.
• Aach regulator hose.
WARNING!

store 

are ignored.
The regulator supplies a pressure of 11 inches. water column to the gas grill and has a QCC1 type ng.
Cylinders to be used with this unit must be supplied with a QCC1 cylinder valve. A QCC1 cylinder has a
posive seang connecon, which will not allow gas ow unl a posive seal has been achieved. It is also
equipped with an excess ow device. In order to aain full ow to the grill, the valves must be in the o
posion when the cylinder valve is turned on.
Natural Gas Hook-Up
This natural gas grill is supplied with a 10 supply hose (complete with a quick disconnect) designed
for natural gas and cered for outdoor use. The gas grill is designed to operate at an inlet pressure
of 7 inches water column. Piping and valves upstream of the quick disconnect are not supplied. The
installaon must comply with CAN B149.1 Natural Gas and Propane installaon code in Canada, or to
the Naonal Fuel Gas Code, ANSI Z223.1 in the United States. The gas supply pipe must be suciently
sized to supply the BTU/h specied on the rang plate, based on the length of the piping run. The quick
disconnect must not be installed in an upward direcon and a readily accessible manual shut-o valve
must be installed upstream of, and as close to, the quick disconnect as is feasible. The ared end of
the hose must be connected to the ng on the end of the ex tube as illustrated in the Natural Gas
Hose Aachment diagram. Tighten using two wrenches. (Do not use thread sealer/pipe dope.) These
connecons must be made by a licensed gas installer. Leak test all joints prior to using the gas grill.
WARNING!
• The installaon must be performed by a licensed gas er, and all connecons must be leak tested
before operang the grill.
• Do not route hose underneath drip pan.
• Do not route hose between space in boom shelf and back panel.
• Do not route hose over top of back panel.
• Ensure all hose connecons are ghtened using two wrenches. Do not use teon tape or
pipe dope on any hose connecon.
• Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a
re.
• Do not use enclosure to store excess hose, as there is a greater chance of the hose contacng a hot
surface, it may melt and leak causing a re.
• Leak test all the connecons using a soap and water soluon, as per the leak tesng instrucons
found in the this manual.
