Napoleon TQ285X User Instructions

35
www.napoleongrills.com
Item Part # Descripon
50 N200-0107 dust cover regulator x
51 N010-0806-SS1SG cart wheel side x
52 N745-0007 wheel 8" x
53 N015-0007 axle x
54 N105-0016 wheel bushing x
55 N160-0026 clip tubing x
56 N450-0043 nut axle cap x
57 N655-0156 support lid handle le x
58 N655-0157 support lid handle right x
59 N390-0003 latch handle x
60 N051-0009 bezel temperature gauge x
61 N685-0015 temperature gauge x
62 N330-0021 hinge right x
63 N330-0020 hinge le x
64 N010-0776-BL4HM lid assembly blue x
65 N215-0013 wind shield x
66 N735-0019 washer, 8mm x
67 N570-0108 screw M8 x 35mm x
68 N570-0109 screw M8 x 60mm x
69 Z450-0015 nut M8 x
70 N485-0022 clevis pin 8mm x 50mm x
71 N570-0110 screw shoulder x
72 N720-0060 ex connector manifold x
73 N555-0058 lighitng rod x
74 N390-0004-BK1SG latch slide x
75 N630-0006 spring x
76 N390-0005-SS1SG latch handle x
77 N500-0042B rubber handle x
78 N570-0019 screw 10-24 x 1/4 x
79 N010-0776-BL4HM-SER assembly lid blue x
80 N475-0319-SER assembly control panel x
81 N010-0820-SER assemlby side shelf x
82 N325-0082T-SER assembly handle top x
83 N325-0082B-SER assembly handle boom x
84 N330-0021-SER assembly hinge right x
85 N330-0020-SER assembly hinge le x
86 N325-0084-SER assembly handle scissor cart foot x
87 N525-0047-BK1SG-SER assembly rail sliding track x
68286 vinyl cover ac
56080 griddle ac
x - standard ac - accessory
Parts List
