Item Part # Descripon
1 N325-0085-SS1SG handle cart x
2 N120-0023 cap nylon x
3 Z570-0036 screw 1/4-20 x 7/8" x
4 N325-0086-SS1SG handle cart shelf x
5 N120-0021 cap shelf le x
6 N120-0022 cap shelf right x
7 N570-0013 screw #8 x 5/8" x
8 N590-0237 shelf le / right x
9 N570-0076 screw #8 x 1/2" x
10 N570-0111 screw #14 x 1 1/4" x
11 N010-0804-SS1SG cart front beam x
12 N010-0805-SS1SG cart rear beam x
13 N525-0047-BK1SG rail sliding track x
14 N530-0049 regulator x
15 N080-0326-BK1SG bracket regulator mount x
16 N570-0026 screw #14 x 1/2" x
17 N450-0039 post nut / shelf pivot x
18 Z735-0009 washer M5 x
19 N570-0107 screw 10-24 30mm x
20 N135-0045-BK1HT base x
21 N570-0104 screw 10-24 x 3/8" x
22 N475-0319 control panel x
23 N010-0773 manifold x
24 N570-0078 screw M4 x 8mm x
25 N585-0089-BK1HT heat shield control panel x
26 N380-0020-RD control knob x
27 N200-0109-BK1HT cover right leg x
28 N200-0108-BK1HT cover le leg x
29 N710-0079 drip pan x
30 N010-0821 bracket drip pan le x
31 N010-0822 bracket drip pan right x
32 N570-0073 screw 1/4-20 x 3/8" x
33 Z570-0033 screw 10-24 x 12mm x
34 N100-0047 burner right x
35 N100-0046 burner le x
36 N655-0158 support handle le x
37 N655-0159 support handle right x
38 Z570-0029 screw 10-24 x 35mm x
39 N325-0082 handle top/boom x
40 N485-0020 clevis pin x
41 N485-0021 coer pin x
42 N080-0302 cross light bracket x
43 N305-0087-BK2FL cooking grid le x
44 N305-0088-BK2FL cooking grid right x
45 N735-0018 washer leg pivot x
46 N570-0026 screw #14 x 1/2" x
47 N720-0067-SS1SG tube cart side x
48 N272-0001 foot scissor cart x
49 N325-0084 handle scissor cart foot x
Parts List
Item Part # Descripon
50 N200-0107 dust cover regulator x
51 N010-0806-SS1SG cart wheel side x
52 N745-0007 wheel 8" x
53 N015-0007 axle x
54 N105-0016 wheel bushing x
55 N160-0026 clip tubing x
56 N450-0043 nut axle cap x
57 N655-0156 support lid handle le x
58 N655-0157 support lid handle right x
59 N390-0003 latch handle x
60 N051-0009 bezel temperature gauge x
61 N685-0015 temperature gauge x
62 N330-0021 hinge right x
63 N330-0020 hinge le x
64 N010-0776-BL4HM lid assembly blue x
65 N215-0013 wind shield x
66 N735-0019 washer, 8mm x
67 N570-0108 screw M8 x 35mm x
68 N570-0109 screw M8 x 60mm x
69 Z450-0015 nut M8 x
70 N485-0022 clevis pin 8mm x 50mm x
71 N570-0110 screw shoulder x
72 N720-0060 ex connector manifold x
73 N555-0058 lighitng rod x
74 N390-0004-BK1SG latch slide x
75 N630-0006 spring x
76 N390-0005-SS1SG latch handle x
77 N500-0042B rubber handle x
78 N570-0019 screw 10-24 x 1/4 x
79 N010-0776-BL4HM-SER assembly lid blue x
80 N475-0319-SER assembly control panel x
81 N010-0820-SER assemlby side shelf x
82 N325-0082T-SER assembly handle top x
83 N325-0082B-SER assembly handle boom x
84 N330-0021-SER assembly hinge right x
85 N330-0020-SER assembly hinge le x
86 N325-0084-SER assembly handle scissor cart foot x
87 N525-0047-BK1SG-SER assembly rail sliding track x
68286 vinyl cover ac
56080 griddle ac
