26
W415-0666 / 01.28.08
#
PART NO. DESCRIPTION
1 W135-0275 OUTER ROCKS
2 W135-0304 SINGLE ROCK
3 W135-0277 BOWL
4 GL-655 ROCK SET ASSEMBLY
5 W565-0090 WIRE MESH
6* W390-0002 DOOR LATCH (EA)
7 W725-0047 NATURAL GAS VALVE - MODULATING
7 W725-0048 PROPANE GAS VALVE - MODULATING
8* W455-0019 NATURAL GAS ORIFICE #43
8* W455-0003 PROPANE GAS ORIFICE #54
9 W680-0005 THERMOCOUPLE **
10 W240-0005 ELECTRODE C/W LEAD
11 W680-0004 THERMOPILE
12 W010- 1194 NATURAL GAS PILOT ASSEMBLY
13 W010- 1201 PROPANE GAS PILOT ASSEMBLY
14* W455-0070 NG PILOT INJECTOR
14* W455-0068 LP PILOT INJECTOR
15* W385-0334 NAPOLEON
®
LOGO
16 W010-1799 FIRESTOP SPACER
17 W100-0099 BURNER
18 GD 552 BLOWER
19 W660-0041 SPARK SWITCH
20 W660-0071 TRANSMITTER
21 W660-0070 RECEIVER
22 W190-0017 DC SPARK UNIT CONTROL
23 W300-0086 NIGHT LIGHT GLASS
24 W387-0006 NIGHT LIGHT LAMP
25 W750-0178 NIGHT LIGHT WIRE HARNESS
26 W290-0080 NIGHT LIGHT LENSE GASKET
27* W361-0027 INSULATION SLEEVE
28 W225-0171 DOOR
29* W500-0205 RESTRICTOR
30* W010-1500 GLASS W/ GASKET
31 W660-0069 FAN CONTROL MODULE
45* W573-0007 HI-TEMP SEALANT
46 GD501 HEAT GUARD
47 GA-566 HOT AIR DISTRIBUTION KIT
48* GA-72 HOT AIR EXHAUST KIT
49 GA-70 EXTENSION KIT, 5FT FLEX VENT
50* W010-0370 WALL SUPPORT ASSEMBLY
51* W175-0001 4” COUPLER
52* W175-0013 7” COUPLER
53* W175-0239 CONVERSION KIT -
NG TO LP
54* W175-0240 CONVERSION KIT - LP TO NG
55 RFK82 RECTANGLE FACING KIT
56 AFK82 ARCHED FACING KIT
57* RFK82WI WROUGHT IRON FACING KIT
Contact your dealer for questions concerning prices and availability
of replacement parts. Normally all parts can be ordered through your
Napoleon® dealer or distributor.
When ordering replacement parts always give the following infor-
mation:
1. MODEL & SERIAL NUMBER OF FIREPLACE
2. INSTALLATION DATE OF FIREPLACE
3. P
ART NUMBER
4. DESCRIPTION OF PART
5. FINISH
Failure to position the parts in accordance with these diagrams or
failure to use only parts specifi cally approved with this appliance
may result in property damage or personal injury.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE
ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM.
REPLACEMENTS
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FUR-
THER INFORMATION, CONTACT YOUR NAPOLEON
®
DEALER.
REPLACEMENT PARTS
ACCESSORIES
GD220 (5 FT)
32* W010-0397 4” FLEXIBLE ALUMINIUM LINER
- (5 FT) C/W SPACERS
32* W410-0017 7” FLEXIBLE ALUMINIUM LINER - (5 FT)
GD330 (10 FT)
33* W010-0300 4” FLEXIBLE ALUMINIUM LINER
- (10 FT) C/W SPACERS
33* W410-0018 7” FLEXIBLE ALUMINIUM LINER - (10 FT)
34* W010-0370 WALL SUPPORT ASSEMBLY
35 PERISCOPE - GD201
36 WALL TERMINAL KIT - GD222R
37* 1/12 TO 7/12 PITCH - GD110
38* 8/12 TO 12/12 PITCH - GD111
39* FLAT ROOF - GD112
40 W490-0073 4/7 INNER/OUTER SLEEVE
41 W670-0006 4/7 TERMINAL
42 W170-0086 STORM COLLAR
43 W010-0453 ROOF SUPPORT
44 W263-0065 / ROOF FLASHING
W263-0066 / ROOF FLASHING
W263-0067 ROOF FLASHING
FLEXIBLE VENT KITS
TERMINAL KITS
ROOF TERMINAL KITS
** This is a fast acting thermocouple. It is an integral safety com-
ponent. Replace only with a fast acting thermocouple supplied
by Wolf Steel Ltd.
!
WARNING
!
WARNING
