ELT-400 8 Specifications
8-5
8.3 Exposure STD (Shaped Time Domain) mode
Brief description
• Measurement of magnetic flux density taking the limit value
characteristic of the selected standard into account.
• RMS and peak values are measured and calculated simultaneously.
• Display of magnetic flux density as a percentage.
A display of 100 % indicates that the limit value has been reached.
Frequency range
Frequency range (-3 dB),
selectable
1 Hz to 400 kHz, 10 Hz to 400 kHz, 30 Hz to 400 kHz
Frequency response As per selected standard, emulated by 1st order filters
at the specified corner frequencies. Additional
attenuation occurs at the selected band limits.
ª see figure C-2
ª see figure C-3
