8 Specifications ELT-400
8-8
Analog signal output “Scope”
1 See under “Measurement range” for the selected operating mode
Measurement probe
Power supply
Battery operation
– or –
Output signal X, Y, Z (isotropic). Three separate channels
Output voltage for nominal
measurement range
(1)
50 mV (RMS)
Output impedance 50 ohm
Load impedance ≥10 kohm
Channel configuration See Annex D: Probe configuration
Effective coil cross sectional
area
100 cm
2
Construction features 3 coils, arranged orthogonally, common center
point
Orientation See Annex D: Probe configuration
External dimensions Diameter: 125 mm
Length: approximately 300 mm
Rechargeable NiMH
batteries, replaceable
4 x Mignon size AA, IEC R6
(e.g. Sanyo HR-3 U)
Operating time from
rechargeable batteries at
23 °C, approximate
12 h
Charging time of
rechargeable batteries, no
measurement operations
2 h max.
