Chapter 7 Counters

Table 7-10. X Series USB Screw Terminal Device Default NI-DAQmx Counter/Timer

Pins

Counter/Timer Signal Default Pin Number (Name)

CTR 0 SRC 81 (PFI 8)

CTR 0 GATE 83 (PFI 9)

CTR 0 AUX 85 (PFI 10)

CTR 0 OUT 89 (PFI 12)

CTR 0 A 81 (PFI 8)

CTR 0 Z 83 (PFI 9)

CTR 0 B 85 (PFI 10)

CTR 1 SRC 76 (PFI 3)

CTR 1 GATE 77 (PFI 4)

CTR 1 AUX 87 (PFI 11)

CTR 1 OUT 91 (PFI 13)

CTR 1 A 76 (PFI 3)

CTR 1 Z 77 (PFI 4)

CTR 1 B 87 (PFI 11)

CTR 2 SRC 73 (PFI 0)

CTR 2 GATE 74 (PFI 1)

CTR 2 AUX 75 (PFI 2)

CTR 2 OUT 93 (PFI 14)

CTR 2 A 73 (PFI 0)

CTR 2 Z 74 (PFI 1)

CTR 2 B 75 (PFI 2)

CTR 3 SRC 78 (PFI 5)

CTR 3 GATE 79 (PFI 6)

CTR 3 AUX 80 (PFI 7)

CTR 3 OUT 95 (PFI 15)

CTR 3 A 78 (PFI 5)

CTR 3 Z 79 (PFI 6)

CTR 3 B 80 (PFI 7)

FREQ OUT 93 (PFI 14)
