National Instruments DAQ X Series User Manual

Chapter 2 DAQ System Overview
X Series User Manual 2-10 ni.com
System features include the following:
• Modular architecture—Select your measurement technology on a
per-channel basis
• Small-channel systems—Condition up to 16 analog input and eight
digital I/O lines
• Low-profile/portable—Integrates well with other laptop computer
measurement technologies
• Connectivity—Incorporates panelette technology to offer custom
connectivity to thermocouple, BNC, LEMO
™
(B Series), and
MIL-Spec connectors
Note (PCI Express X Series Devices) PCI Express users should consider the power limits on
certain SCC modules without an external power supply. Refer to the specifications for your
device, and the PCI Express Device Disk Drive Power Connector section of Chapter 3,
Connector and LED Information, for information about power limits and increasing the
current the device can supply on the +5 V terminal.
Note (NI 6356/6358/6366/6368 Devices) XSeries Simultaneous MIO (SMIO) devices do not
support SCC.
Programming Devices in Software
National Instruments measurement devices are packaged with NI-DAQmx
driver software, an extensive library of functions and VIs you can call from
your application software, such as LabVIEW or LabWindows/CVI, to
program all the features of your NI measurement devices. Driver software
has an application programming interface (API), which is a library of VIs,
functions, classes, attributes, and properties for creating applications for
your device.
X Series devices use the NI-DAQmx driver. NI-DAQmx includes a
collection of programming examples to help you get started developing an
application. You can modify example code and save it in an application.
You can use examples to develop a new application or add example code to
an existing application.
To locate LabVIEW, LabWindows/CVI, Measurement Studio, Visual
Basic, and ANSI C examples, refer to the KnowledgeBase document,
Where Can I Find NI-DAQmx Examples?, by going to
ni.com/info and
entering the Info Code
daqmxexp.
For additional examples, refer to
zone.ni.com.
