Chapter 10 Bus Interface
© National Instruments 10-3 X Series User Manual
PXI Express Considerations
PXI clock and trigger signals are only available on PXI Express devices.
PXI and PXI Express Clock and Trigger Signals
Refer to the PXI_CLK10, PXI Triggers, PXI_STAR Trigger, PXI_STAR
Filters, PXIe-DSTAR<A..C>, PXIe_CLK100, and PXIe_SYNC100
sections of Chapter 9, Digital Routing and Clock Generation, for more
information about PXI and PXI Express clock and trigger signals.
PXI Express
X Series PXI Express devices can be installed in any PXI Express slot in
PXI Express chassis.
PXI Express specifications are developed by the PXI System Alliance
(
www.pxisa.org).
