Chapter 8 PFI

Exporting Timing Output Signals Using PFI Terminals

You can route any of the following timing signals to any PFI terminal

configured as an output:

•

(NI 632x/634x/6351/6353/6361/6363 Devices) AI Convert Clock

(ai/ConvertClock)

• AI Hold Complete Event (ai/HoldCompleteEvent)

• AI Reference Trigger (ai/ReferenceTrigger)

• AI Sample Clock (ai/SampleClock)

• AI Start Trigger (ai/StartTrigger)

•AI Pause Trigger (ai/PauseTrigger)

• AO Sample Clock

(ao/SampleClock)

• AO Start Trigger (ao/StartTrigger)

•AO Pause Trigger (ao/PauseTrigger)

• DI Sample Clock (di/SampleClock)

• DI Start Trigger (di/StartTrigger)

• DI Reference Trigger (di/ReferenceTrigger)

•DI Pause Trigger (di/PauseTrigger)

• DO Sample Clock

(do/SampleClock)

• DO Start Trigger (do/StartTrigger)

• DO Pause Trigger (do/PauseTrigger)

•Counter n Source

•Counter n Gate

•Counter n Internal Output

•Counter n Sample Clock

•Counter n Counter n HW Arm

•Frequency Output

•PXI_STAR

•RTSI<0..7>

• Analog Comparison Event

• Change Detection Event

• Watchdog timer expired pulse

Note Signals with an

are inverted before being driven to a terminal; that is, these signals

are active low.
