Peripheral External Connector Description
USB USB 4-pin Series A stacked
receptacle (4 ports)
Hi-Speed USB
USB 9-pin Series A stacked
receptacle (2 ports)
SuperSpeed USB, backwards
compatible with USB 2.0
PXI trigger Trigger (SMB) Routing PXI triggers to or from the
backplane trigger bus
GPIB device GPIB (25-pin Micro D) General-Purpose Interface Bus, IEEE
488.1
ExpressCard/34
module
ExpressCard/34 slot ExpressCard/34 Expansion
PXI Express Trigger Connectivity
The SMB connector on the NI PXIe-8840 Quad-Core front panel can connect to or
from any PXI Express backplane trigger line. A trigger allocation process is needed to
prevent two resources from connecting to the same trigger line, resulting in the
trigger being double-driven and possibly damaging the hardware. At the time of this
manual’s publication, this soware is not yet available for Windows. Contact
National Instruments for more information.
Front Panel Features
The NI PXIe-8840 Quad-Core has the following front-panel features:
■
A controller reset push button (press the button to generate a reset to the
controller)
■
Two front panel LEDs that show PC status:
■
DRIVE LED— Indicates when an access to the internal hard disk is
occurring.
■
PWR OK/FAULT LED—Indicates the controller status. The LED indicates
one of the following states:
■
Green ON steady—PXI and onboard power is on and within
regulation limits.
ni.com
14
PXIe-8840 Quad Core
