SCXI-1120/D Front Connector
Figure 3-1 shows the pin assignments for the SCXI-1120/D front
connector.
Figure 3-1.
SCXI-1120/D Front Connector Pin Assignments
CHSGND
+5 V
RSVD
CH7+
CH6+
CH5+
CH4+
CH3+
CH2+
CH1+
NC
NC
NC
NC
NC
CH0+
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
AB
DTEMP
MTEMP
RSVD
RSVD
CH7-
CH6-
CH5-
CH4-
CH3-
CH2-
CH1-
NC
NC
NC
NC
CH0-
C
- This symbol represents no physical pin
