About This Manual
This manual describes the electrical and mechanical aspects of the
SCXI-1120 and SCXI-1120D (SCXI-1120/D) modules and contains
information concerning their installation and operation.
The SCXI-1120 and SCXI-1120D are National Instruments Signal
Conditioning eXtensions for Instrumentation (SCXI) Series modules.
The SCXI-1120/D provides eight isolated input channels. Each channel
is independently configurable through jumpers.
The SCXI-1120 module is designed for low-cost signal conditioning of
thermocouples, volt sources, millivolt sources, and 4 to 20 mA sources
or 0 to 20 mA process-current sources where high common-mode
voltages exist.
The SCXI-1120D module is designed for low-cost signal conditioning
of volt, millivolt, and current sources that require a 20 kHz bandwidth
and where high common-mode voltages exist.
Conventions
The following conventions appear in this manual:
♦ The ♦ symbol indicates that the following text applies only to a specific
product, a specific operating system, or a specific software version.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
Lab/1200 Lab device refers to the Lab-LC, Lab-NB, Lab-PC, Lab-PC+,
Lab-PC-1200, and Lab-PC-1200AI.
PC PC refers to the IBM PC/XT, the IBM PC AT, and compatible computers.
SCXI-1120 SCXI-1120 refers to only the SCXI-1120 module.
