NV30/NV40 Operations and Maintenance Manual Operating the transmitter
Issue 3.3 2014-12-10 Page 2-57
– Auto Changeover Action: users can select which preset they want the
transmitter to switch to in the event of an automatic exciter changeover.
This function is ideal for changing to a preset that has a different HD PA
Volts value, which is required when a different exciter is active - e.g. HD
Power Boost active exciter A requires less HD PA Volts to comply with
spectral mask, thus improving dissipation. However if an automatic
changeover to non-HD Power Boost enabled exciter B occurs, the Auto
Changeover Action
preset will have a higher HD PA Volts value (less
efficient, but required in order to comply with spectral limits).
–Mod Loss Timeout: select Enable if so required. If Enable is selected the
following sub-fields will appear:
– Action: select the action to take on the loss of a modulating signal
post the timeout period. Select None (no resulting action), Inhibit
(inhibits the RF output and fans until the audio returns) or Change
Preset
(changes the active preset).
– Mod Loss Preset: displayed only if Action is set to Change Preset.
Select the preset from the drop down list that will activate upon the
loss of a modulating signal, post the timeout period.
– Timeout Minutes: sets the delay, in minutes, between modulation
loss detection and the resulting action. Enter a value in the allowable
range of 0 and 255 minutes.
– Timeout Seconds: sets the delay, in seconds, between modulation
loss detection and the resulting action. Enter a value in the allowable
range of 0 and 59.9 seconds.
–
Threshold: sets the threshold for modulation loss detection. Enter
a value in the allowable range of 0 and 100%.
–Hard Limiter: select Enabled, then enter the hard limit threshold
percentage (allowable range is 0-160%, defaulted to 140%). If enabled,
the modulation level will be limited (audio signal clipped or distorted) if it
exceeds the hard limit threshold.
