Continued from previous page
NAPI111
Module Backplane PWB Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
J01 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J02 JF35Conn, BNC, Recept, PWB Mt R141426161 0GP12
J03 JF47Conn, Header,Square Post,Gold,Dual,40-pin 4-102973-0 09482
J04 JT77Connector,Modular,Dual,RJ-45Jack Rt Agl, PWB 569381-1 09482
J05 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J06 JF35Conn, BNC, Recept, PWB Mt R141426161 0GP12
J07 JF47Conn, Header,Square Post,Gold,Dual,40-pin 4-102973-0 09482
J08 JT77Connector,Modular,Dual,RJ-45Jack Rt Agl, PWB 569381-1 09482
J09 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J10 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J11 JF35Conn, BNC, Recept, PWB Mt R141426161 0GP12
J12 JF47Conn, Header,Square Post,Gold,Dual,40-pin 4-102973-0 09482
J13 JT77Connector,Modular,Dual,RJ-45Jack Rt Agl, PWB 569381-1 09482
J14 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J15 JF35Conn, BNC, Recept, PWB Mt R141426161 0GP12
J16 JF47Conn, Header,Square Post,Gold,Dual,40-pin 4-102973-0 09482
J17 JT77Connector,Modular,Dual,RJ-45Jack Rt Agl, PWB 569381-1 09482
J18 JN59Conn,Edge Card,88 Contacts,Dual Row,30u Gold, M3 346-088-620-207 31781
J19 JN59Conn,Edge Card,88 Contacts,Dual Row,30u Gold, M3 346-088-620-207 31781
J20 JN59Conn,Edge Card,88 Contacts,Dual Row,30u Gold, M3 346-088-620-207 31781
J21 JN59Conn,Edge Card,88 Contacts,Dual Row,30u Gold, M3 346-088-620-207 31781
R01 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R02 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R03 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R04 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R05 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R06 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R07 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R08 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R09 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R10 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R11 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R12 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R13 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R14 RD02Resistor, Film, 3900 Ohms, 2PC 1/2W RL20S392G 35005
R15 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
R16 RAB17Resistor, MF, 221 Ohms, 1PC 1/4W MF1/4DL2210F 59124
S01 SB49Switch, DIP, Rotary, 16-pos,BC-Hexidecimal SD1010(RoHS)
S02 SB49Switch, DIP, Rotary, 16-pos,BC-Hexidecimal SD1010(RoHS)
Page 71 of 82
NAPI111
