Continued from previous page
NAPI115A
Remote Interface PWB Assy, NV
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
E21 JQ15Conn, Post Shunt, 2 Pos, .10 Centreline 390088-2 09482
E22 JQ15Conn, Post Shunt, 2 Pos, .10 Centreline 390088-2 09482
E23 JQ15Conn, Post Shunt, 2 Pos, .10 Centreline 390088-2 09482
E24 JQ15Conn, Post Shunt, 2 Pos, .10 Centreline 390088-2 09482
J01 JQ51Conn, Plug, D-Sub, 37-Pin PWB, 90 621-037-260-043 EDAC
J02 200-5090Conn, Socket 37-pin D-SUB, 90Kit 200-5090 37338
J03 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J04 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J05 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J06 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J07 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J08 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J09 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J10 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J11 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
J12 JR51Terminal Block,2-pos,PWB Mount 1803277(ROHS) PHOENIX
J13 JR51Terminal Block,2-pos,PWB Mount 1803277(ROHS) PHOENIX
J14 JR53Terminal Block,8-pos,PWB Mount,90 Deg 1803332(ROHS) PHOENIX
R01 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R02 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R03 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R04 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R05 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R06 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R07 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R08 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R09 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R10 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R11 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R12 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R13 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R14 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R15 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R16 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R17 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R18 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R19 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R20 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
R21 RAD27Resistor, SMT, MF, 1500 Ohms,1% 1/4W RK73H2BL1501F 59124
Page 78 of 82
NAPI115A
