Nautel NV5 - Page 151

NARF50B
Final Assy, NV5/NV3.5 (RLS 3)
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
A01 NAPC156AControl/Interface PWB Assy, NV Series 206-2010-01 37338
A02 NAPI115ARemote Interface PWB Assy, NV 206-4120-01 37338
A03
NVE Exciter A, Digital, FM NAE104A or /01 206-3400-02 37338
A04 NVE Exciter B, Digital, FM (Optional) NAE104A or /01 206-3400-02 37338
A05 NAI17RF Drive Splitter/ChangeoverAssy, NV5 206-8350 37338
A06 206-5150-01AC Distribution Assy (2x3way) 206-5150-01 37338
A07 NAPI112BPower Supply Distribution PWB Assy 206-7060-02 37338
A08 206-4060Power Supply Interface PWBAssy 206-4060 37338
A09 206-4060Power Supply Interface PWBAssy 206-4060 37338
A10 206-4060Power Supply Interface PWBAssy 206-4060 37338
A100
UPS Interface Assembly (Optional) 206-5145-01 206-5145-01 37338
A11 206-4060Power Supply Interface PWBAssy 206-4060 37338
A12 -Not Used NOT USED 37338
A13 NAFP109APower Probe Assy, NV 206-6500-01 37338
A14 NAL09A2 Input Reject Load Assy 206-6250-01 37338
A15 206-4084Reject Load Interface PWB Assy (4-Way) 206-4084 37338
A16 NAF119ACombiner/Filter Assy, 5kW 206-6000-03 37338
A17 NAPI111Module Backplane PWB Assy 206-4050 37338
A18 NAA56/01DRF Power Module Assy, NV Series RLS 3 206-1000-05 37338
A19 206-4060Power Supply Interface PWBAssy 206-4060 37338
A20 206-4060Power Supply Interface PWBAssy 206-4060 37338
A21 NAA56/01DRF Power Module Assy, NV Series RLS 3 206-1000-05 37338
A22 206-4060Power Supply Interface PWBAssy 206-4060 37338
A23 206-4060Power Supply Interface PWBAssy 206-4060 37338
B01 206-8406Fan Bracket Assy, NV Door 206-8406 37338
CR01 UR94Diode, Pwr Rect, Schottky(BeO)170V 2x100A STPS200170TV1(Stati
cs)(RoHS)
DS01 BAP44LED, Pilot Light, Amber, 230Vac LEDTECA220AC
DS02 BAP44LED, Pilot Light, Amber, 230Vac LEDTECA220AC
DS03 BAP44LED, Pilot Light, Amber, 230Vac LEDTECA220AC
L01 LP33Toroid, Ferrite, Mtl 43, 1.40"OD, 0.9" ID FT-140-43
TB01 JR56Pwr Dist Block, 175A, 2/0-8AWG x 1, 4-14 AWG x 4 PDBFS220
U01 UG57Power Supply, 12V@200W, 85-264VAC, PFC SP-200-12 S8116
U02 UG57Power Supply, 12V@200W, 85-264VAC, PFC SP-200-12 S8116
U03 UG68Power Supply, Univ Input, 5V, +/-15V, 75W, PFC TP-75C
U04 UG68Power Supply, Univ Input, 5V, +/-15V, 75W, PFC TP-75C
U05 206-5400-01Touchscreen Monitor Kit Assy (UR108) 206-5400-01 37338
U06 206-8973Single Board Computer Assy 206-8973 37338
Page 81 of 82
NARF50B
