Nautilus R616 User Manual

6
Item Qty Description Item Qty Description
1 1 Console 10 1 Rear Stabilizer
2 1 Water Bottle Holder 11 1 Left Pedal
3 1 Seat Back 12 1 Front Stabilizer
4 1 Seat Cover 13 1 Right Pedal
5 1 Seat Frame Assembly 14 1 Top Shroud
6 1 Seat Bottom 15 1 Console Mast
7 1 Seat Adjustment Handle 16 1 MP3 Cord
8 1 Frame 17 1 AC Adapter
9 1 Seat Rail End Cap
PARTS
17
15
14
12
16
9
1
7
13 (R)
11 (L)
4
3
5
10
2
6
8

Nautilus R616 Specifications

General

Brand	Nautilus
Model	R616
Category	Elliptical Trainer
Language	English
